Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Name: Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter
Brand: KLSK
Price: 1 USD

Quality Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter wholesale

Place of Origin : Jiangsu, China

Brand Name : KLSK

Model Number : WT-602

Certification : CE

Packaging Details : Standard exporting package-Carton box

MOQ : 1PC

Price : $1,200.00/pieces

Warranty : 1 years

Type : Dust analyzer

Customized support : OEM

Working wavelength : 650nm

Product name : Dust Monitoring Equipment

Gas analyzer principle : Scattered light backward

Application : Online Stack Dust Monitor

Power : 24VDC+/-10%

Work temperature : -40 ℃-+50 ℃

Measure Range : 0~200mg/m3, 0~10g/m3

Signal output : (4-20) mA

Response time : ≤ 10s

Stock : 1PC

Contact Now

WT602 Series Continuous Gas Monitoring System Industrial Waste Gas and Smoke Dust Meter

>>> Working Principle

WT602B series products use the principle of laser backscatter to complete the measurement of flue dust concentration. The embedded high stable laser signal source passes through the flue and irradiates the smoke particles. The irradiated smoke particles will reflect the laser signal, and the reflected signal intensity changes positively with the smoke concentration. The concentration of flue dust can be calculated by a specific algorithm.

Online Stack Dust Monitor WT602 for Industrial Waste Gas And Smoke Dust Meter

Product Description

Technical Specification

Parameters	WT602
Principle	Laser backscatter
Working wavelength	650nm
Zero drift	±2%F.S./24h
Range drift	±2%F.S./24h
Indication error	±15%
Response time	≤ 10s
Diameter of flue	(1-15)m
Operating temperature	(-40~+65) ºC
Flue temperature	<200ºC
Flue pressure	<1Kpa
Signal output	(4-20) mA
Power supply	DC 24V ± 10%
